Stirring Hotplate
Individualized versions and non-standard device sizes available on request
Replacement controller for STIRRING HOTPLATE and STIRRING DRYBATH (included in delivery)
High-performance magnetic stir bar
Sample probe for heatMIXcontrol controller
PTFE-coated flexible stirring bar remover
Vertical mounting support for heatMIXcontrol
manual operator
German operator manual for the 2mag STIRRING DRYBATH 15-100/15-250/8-250 ERL and STIRRING HOTPLATE 6/15 with heatMIXcontrol heating and stirring systems, version 6.1.
manual operator
English operator manual for the 2mag STIRRING DRYBATH 15-100/15-250/8-250 ERL and STIRRING HOTPLATE 6/15 with heatMIXcontrol heating and stirring systems, version 6.1.
2mag AG
Connect directly with 2mag AG to request pricing, samples and lead times for STIRRING HOTPLATE 15.
The 2mag STIRRING HOTPLATE 15 is a 15-position stirring hotplate with 65 mm position spacing, universally suited to various vessel sizes and forms, and optimized for 15 × 250 ml tall-form beakers. It combines an inductive wear-free magnetic drive with integrated electric heating up to +200°C and includes the stainless steel heatMIXcontrol controller.
| Stirring positions | 15 |
|---|---|
| Position spacing | 65 mm |
| Stirring volume per position | 1-1,000 ml |
| Max stirring power | 40 W |
| Power adjustment | 10-100% (10 levels) |
| Temperature range | +40°C to +200°C |
| Speed range | 100-2,000 rpm |
| Operating voltage | 230 V |
| Max heating power at 230 V | 1,200 W |
| Dimensions (W×D×H) | 250 × 430 × 75 mm |
| Protection class | IP20 |
|---|
| Shipping weight (gross) | approx. 13.0 kg |
|---|
| Part number | 66315 |
|---|
